In the realm of security surveillance, the ability to detect threats promptly and effectively is paramount. From protecting critical infrastructure to ensuring public safety, the demand for advanced surveillance solutions capable of preempting potential risks has never been greater. In this context, thermal imaging technology has emerged as a game-changer, offering unparalleled capabilities in threat detection and intervention. As a leader in the field, Dahua Technology has leveraged its expertise to develop cutting-edge thermal cameras that redefine the boundaries of surveillance effectiveness.
**Evolution of Thermal Imaging Technology:**
The journey of thermal imaging technology traces back to the 1950s, with the development of cooled infrared detectors. Over the decades, advancements in uncooled infrared detectors have democratized thermal imaging, making it accessible across various industries. Today, Dahua thermal cameras stand at the forefront of this evolution, embodying the pinnacle of innovation and reliability.
**Advantages and Features of DAHUA Thermal Cameras:**
Dahua thermal cameras offer a myriad of advantages and features that distinguish them in the market:
DAHUA TPC-KF2241-T
TPC-KF2241-T
Dahua Thermal Network Hybrid Compact Camera
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Ultra wide-angle lens.
> Built-in white light.
> Temperature measurement range of –20 °C to +550 °C.
> Magnet mount to power distribution cabinet.
> IP67 rated.
> Supports surge protection of 6 kV, air discharge of 15 kV, and contact discharge of 8 kV.
DAHUA THSD-PTZ6442-T Thermal Hybrid Speed Dome Camera
THSD-PTZ6442-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Visible lens offers 45× optical zoom.
> Offers various AI functions such as boat, smoke, and fire detection,tripwire, target filtering and intrusion detection.
> Built-in IR LED, and the IR illumination distance ≥100 m.
> Dual image fusion (visible and thermal images).
> 36 VDC ± 50%/Hi-PoE power supply.
> IP66 rated.
> Temperature measurement range of –20 °C to +550 °C.
DAHUA
DAHUA TPC-ACPT8620A-B Thermal Network Anti-corrosion Hybrid Pan & Tilt Camera
TPC-ACPT8620A-B
Thermal Network Anti-corrosion Hybrid Pan & Tilt Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support fire detection & alarm
> Max 160°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, 256GB
> Anti-corrosion/NEMA 4X, IP67
DAHUA TPC-ACPT8420A-B Thermal Network Anti-corrosion Hybrid Pan & Tilt Camera
TPC-ACPT8420A-B
Thermal Network Anti-corrosion Hybrid Pan & Tilt Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support fire detection & alarm
> Max 160°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, 256GB
> Anti-corrosion/NEMA 4X, IP67
DAHUA TPC-ACSD8420-B Thermal Network Anti-corrosion Hybrid Speed Dome Camera
TPC-ACSD8420-B
Thermal Network Anti-corrosion Hybrid Speed Dome Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support fire detection & alarm
> Max 240°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, 256GB
> Anti-corrosion/NEMA 4X, IP66
DAHUA TPC-BF1241 WizSense Thermal Network Bullet Camera
TPC-BF1241
WizSense Thermal Network Bullet Camera
> Athermalized lens (thermal camera), focus-free
> 1/2.7” 4Megapixel progressive scan CMOS
> Wi-Fi Optional
> Support ROI, motion detection, color palettes
> Smoking and call behaviour detection
> Support fire detection & alarm
> Built-in 1/1 alarm in/out
> Micro SD memory, IP67, PoE
> Smart linkage with strobe light & audio
> Dual image fusion (visible and thermal images)
DAHUA TPC-BF1241-S2 Thermal Network Mini Hybrid Bullet Camera
TPC-BF1241-S2
Thermal Network Mini Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: heat detection, tripwire, human/vehicle classification, smoking detection, and call detection.
> Remote auxiliary management.
> Dual image fusion (visible and thermal channels).
> Wide input voltage 12 VDC ± 20%, and PoE.
> IP67 rated.
DAHUA TPC-BF1241-T-S2 Thermal Network Mini Hybrid Bullet Camera
TPC-BF1241-T-S2
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: heat detection, tripwire, human/vehicle classification, smoking detection, and call detection.
> Temperature measurement range of –20 °C to +400 °C.
> Flexible rules and alarms.
> Remote auxiliary management.
> Dual image fusion (visible and thermal channels).
> Wide input voltage 12 VDC ± 20%, and PoE.
> IP67 rated.
DAHUA TPC-BF1241-T WizSense Thermal Network Bullet Camera
TPC-BF1241-T
WizSense Thermal Network Bullet Camera
> Athermalized lens (thermal camera), focus-free
> 1/2.7” 4Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Smoking and call behaviour detection
> Support fire detection & alarm
> Built-in 1/1 alarm in/out
> Micro SD memory, IP67, PoE
> Smart linkage with strobe light & audio
> Temperature measurement
> Dual image fusion (visible and thermal images)
DAHUA TPC-BF2221-T Thermal Network Hybrid Bullet Camera
TPC-BF2221-T
Thermal Network Hybrid Bullet Camera
> 256×192 VOx uncooled thermal sensor technology
> Athermalized lens (thermal camera), focus-free
> 1/2.8” 2Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Support temperature measurement
> Support fire detection & alarm
> Built-in 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePOE
DAHUA TPC-BF2221 Thermal Network Value Hybrid Bullet Camera
TPC-BF2221
Thermal Network Value Hybrid Bullet Camera
> 256×192 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> 1/2.8” 2Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Smart alarm linkage with white light & loudspeaker
> Support Fire detection & alarm
> Built-in 2/2 alarm in/out
> Micro SD memory, IP67, PoE/ePoE
DAHUA TPC-BF2241 Thermal Network Hybrid Bullet Camera
TPC-BF2241
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Offers various AI functions such as intrusion, target filtering, heat detection, smoking detection, and calling detection.
> Built-in white light and speaker that produce light and sound alarms to deter intruders.
> Built-in IR LED with a maximum illumination distance of 35 m.
> Dual image fusion (visible and thermal images).
> 12 VDC ± 20%/PoE power supply.
> IP67 rated.
DAHUA TPC-BF5300 Thermal Network Bullet Camera
TPC-BF5300
Thermal Network Bullet Camera
> 336×256 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support Fire detection & alarm
> Various lens optional (7.5/13/19/25/35mm)
> 2/1 alarm in/out
> Micro SD memory, IP67, PoE
DAHUA TPC-BF2241-T Thermal Network Hybrid Bullet Camera
TPC-BF2241-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Offers various AI functions such as intrusion, target filtering, heat detection, smoking detection, and calling detection.
> Temperature measurement range of –20 °C to +550 °C (–4 °F to +1022 °F).
> Built-in white light and speaker that produce light and sound alarms to deter intruders.
> Built-in IR LED, and the max. illumination distance 35 m.
> Dual image fusion (visible and thermal images).
> 12 VDC ± 20%/PoE power supply.
> IP67 rated.
DAHUA TPC-BF5300-T Thermal Network Bullet Camera
TPC-BF5300-T
Thermal Network Bullet Camera
> 336×256 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Support Fire detection & alarm
> Various lens optional (7.5/13/19/25/35mm)
> 2/1 alarm in/out
> Micro SD memory, IP67, PoE
DAHUA TPC-BF5401 Thermal Network Bullet Camera
TPC-BF5401
Thermal Network Bullet Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support Fire detection & alarm
> Various lens optional (7.5/13/25/35mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
DAHUA TPC-BF5400-TB Thermal Network Bullet Camera
TPC-BF5400-TB
Thermal Network Bullet Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Support Fire detection & alarm
> Various lens optional (7.5/13/19/25/35mm)
> 2/1 alarm in/out
> Micro SD memory, IP67, PoE
DAHUA TPC-BF5401-T-S2 Thermal Network Bullet Camera
TPC-BF5401-T-S2
Thermal Network Bullet Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Various lens optional (7.5/13/25/35mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
DAHUA TPC-BF5421 Thermal Network Hybrid Bullet Camera
TPC-BF5421
Thermal Network Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> Uses a 1/2.8 inch CMOS image sensor.
> Supports fire detection, smoking detection, tripwire, intrusion, call detection, target classification, and alarm linkages.
> Built-in white light and speaker.
> View videos on the web, app, PC and more.
> Micro SD memory, IP67, PoE, ePoE.
> Supports up to 18 color palettes.
DAHUA TPC-BF5401-T Thermal Network Bullet Camera
TPC-BF5401-T
> 400 × 300 uncooled VOx thermal sensor technology
> Athermalized lens (thermal), focus-free
> Support temperature measurement
> Various lens optional (7.5/13/25 mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE,ePoE
DAHUA TPC-BF5401-T-S2 DAHUA TPC-BF5401-S2 Thermal Network Bullet Camera
TPC-BF5401-T-S2
Thermal Network Bullet Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Various lens optional (7.5/13/25/35mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
DAHUA TPC-BF5421-T Thermal Network Hybrid Bullet Camera
TPC-BF5421-T
Thermal Network Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> Uses a 1/2.8 inch CMOS image sensor.
> Supports fire detection, smoking detection, tripwire, intrusion, call detection, target classification, and alarm linkages.
> Features temperature measurement.
> Built-in white light and speaker.
> View videos on the web, app, PC and more.
> Micro SD memory, IP67, PoE, ePoE.
> Supports up to 18 color palettes.
DAHUA TPC-BF5441 Thermal Network Hybrid Bullet Camera
TPC-BF5441
Thermal Network Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> 1/1.8″ 4Megapixel progressive scan CMOS.
> Heat detection and alarm, tripwire, intrusion, and target filtering.
> Junction box optional.
> Illumination distance is up to 80 m.
> IP67 rated.
> Wide input voltage 12 VDC ± 20%, and PoE power supply.
> Smart linkage of white light and audio.
DAHUA TPC-BF5600-T Thermal Network Bullet Camera
TPC-BF5600-T
Thermal Network Bullet Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Support Fire detection & alarm
> Various lens optional (9/13/19/25/35mm)
> 2/1 alarm in/out
> Micro SD memory, IP67, PoE
DAHUA TPC-BF5441-T Thermal Network Hybrid Bullet Camera
TPC-BF5441-T
Thermal Network Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> 1/1.8″ 4Megapixel progressive scan CMOS.
> Heat detection and alarm, tripwire, intrusion, and target filtering.
> Junction box optional.
> Illumination distance is up to 80 m.
> IP67 rated.
> Wide input voltage 12 VDC ± 20%, and PoE power supply.
> Smart linkage of white light and audio.
> Temperature measurement range of –20 °C to +550 °C.
DAHUA TPC-BF5600-TB Thermal Network Bullet Camera
TPC-BF5600-TB
Thermal Network Bullet Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Support Fire detection & alarm
> Various lens optional (7.5/13/19/25/35mm)
> 2/1 alarm in/out
> Micro SD memory, IP67, PoE
DAHUA TPC-BF5600 Thermal Network Bullet Camera
TPC-BF5600
Thermal Network Bullet Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support Fire detection & alarm
> Various lens optional (9/13/19/25/35mm)
> 2/1 alarm in/out
> Micro SD memory, IP67, PoE
DAHUA TPC-BF5601 Thermal Network Bullet Camera
TPC-BF5601
Thermal Network Bullet Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support Fire detection & alarm
> Various lens optional (7.5/13/25/35mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
DAHUA TPC-BF5601-T-S2 Thermal Network Bullet Camera
TPC-BF5601-T-S2
Thermal Network Bullet Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support temperature measurement
> Various lens optional (7.5/13/25/35mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
DAHUA TPC-BF5601-S2 Thermal Network Bullet Camera
TPC-BF5601-S2
Thermal Network Bullet Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support Fire detection & alarm
> Various lens optional (7.5/13/25/35mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
DAHUA TPC-BF5601-T Thermal Network Bullet Camera
TPC-BF5601-T
Thermal Network Bullet Camera
> 640 × 512 uncooled VOx thermal sensor technology
> Athermalized lens (thermal), focus-free
> Support temperature measurement
> Various lens optional (7.5/13/25 mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE,ePoE
DAHUA TPC-BF5641 Thermal Network Hybrid Bullet Camera
TPC-BF5641
Thermal Network Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> 1/1.8″ 4Megapixel progressive scan CMOS.
> Heat detection and alarm, tripwire, intrusion, and target filtering.
> Junction box optional.
> Illumination distance is up to 80 m.
> IP67 rated.
> Wide input voltage 12 VDC ± 20%, and PoE power supply.
> Smart linkage of white light and audio.
DAHUA TPC-BF5641-T Thermal Network Hybrid Bullet Camera
TPC-BF5641-T
Thermal Network Hybrid Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> 1/1.8″ 4Megapixel progressive scan CMOS.
> Heat detection and alarm, tripwire, intrusion, and target filtering.
> Junction box optional.
> Illumination distance is up to 80 m.
> IP67 rated.
> Wide input voltage 12 VDC ± 20%, and PoE power supply.
> Smart linkage of white light and audio.
> Temperature measurement range of –20 °C to +550 °C.
DAHUA TPC-DF1241 WizSense Thermal Network Eyeball Camera
TPC-DF1241
WizSense Thermal Network Eyeball Camera
> Athermalized lens (thermal camera), focus-free
> 1/2.7” 4Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Smoking and call behaviour detection
> Support fire detection & alarm
> Built-in 1/1 alarm in/out
> Micro SD memory, IP67, PoE
> Smart linkage with strobe light & audio
> Dual image fusion (visible and thermal images)
DAHUA TPC-DF1241-S2 Thermal Network Mini Hybrid Eyeball Camera
TPC-DF1241-S2
Thermal Network Mini Hybrid Eyeball Camera
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: heat detection, tripwire, human/vehicle classification, smoking detection, and call detection.
> Remote auxiliary management.
> Dual image fusion (visible and thermal channels).
> Wide input voltage 12 VDC ± 20%, and PoE.
> IP67 rated.
DAHUA TPC-DF1241-T WizSense Thermal Network Eyeball Camera
TPC-DF1241-T
WizSense Thermal Network Eyeball Camera
> Athermalized lens (thermal camera), focus-free
> 1/2.7” 4Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Smoking and call behaviour detection
> Support fire detection & alarm
> Built-in 1/1 alarm in/out
> Micro SD memory, IP67, PoE
> Smart linkage with strobe light & audio
> Temperature measurement
> Dual image fusion (visible and thermal images)
DAHUA TPC-DF1241-T-S2 Thermal Network Mini Hybrid Eyeball Camera
TPC-DF1241-T-S2
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: heat detection, tripwire, human/vehicle classification, smoking detection, and call detection.
> Temperature measurement range of –20 °C to +400 °C.
> Flexible rules and alarms.
> Remote auxiliary management.
> Dual image fusion (visible and thermal channels).
> Wide input voltage 12 VDC ± 20%, and PoE.
> IP67 rated.
DAHUA TPC-PT8320B Thermal Network Hybrid PTZ
TPC-PT8320B
Thermal Network Hybrid PTZ
Recommended Replacement:
> 336×256 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful optical zoom lens(Thermal&Visible)
> Support fire detection & alarm
> Max 12°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/2 alarm in/out
> Micro SD memory, IP66Series
DAHUA TPC-HI20 Thermal Handheld Thermographic Camera
TPC-HI20
Thermal Handheld Thermographic Camera
> Built with an industry-leading vanadium oxide uncooled focal plane detector, it is highly sensitive and produces high-quality images
> Supports the accurate measuring of temperatures, with a tolerance of less than Max (±2 °C, ±2%) and a range of –20 °C to +550 °C
> Supports SD card storage
> Features 4 pseudo-color modes: Whitehot, Blackhot, Rainbow, and Ironbow
> Uses buzzer alarm when a temperature exceeds the alarm threshold
> Automatically captures images when a temperature exceeds the threshold
> Supports device exception alerts
> Supports image enhancement
> Supports laser Pointer
> Supports cold/Hot spot trace
DAHUA TPC-KF2241-T Dahua Thermal Network Hybrid Compact Camera
TPC-KF2241-T
Dahua Thermal Network Hybrid Compact Camera
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Ultra wide-angle lens.
> Built-in white light.
> Temperature measurement range of –20 °C to +550 °C.
> Magnet mount to power distribution cabinet.
> IP67 rated.
> Supports surge protection of 6 kV, air discharge of 15 kV, and contact discharge of 8 kV.
DAHUA TPC-PT8420M-TB Thermal Network Mobile Hybrid Pan & Tilt Camera
TPC-PT8420M-TB
Thermal Network Mobile Hybrid Pan & Tilt Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support temperature measurement
> Support fire detection & alarm
> Max 90°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8421A Thermal Network Hybrid Pan & Tilt Camera
TPC-PT8421A
Thermal Network Hybrid Pan & Tilt Camera
> 400 x 300 VOx uncooled thermal sensor technology
> Athermalized lens(thermal), focus-free
> 1/2.8” 2 megapixel progressive scan CMOS
> Support detection and alarm of fire
> Max 140°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8420A-TB Thermal Network Hybrid Pan & Tilt Camera
TPC-PT8420A-TB
Thermal Network Hybrid Pan & Tilt Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support temperature measurement
> Support fire detection & alarm
> Max 160°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP67
DAHUA TPC-PT8420M-B Thermal Network Mobile Hybrid Pan & Tilt Camera
TPC-PT8420M-B
Thermal Network Mobile Hybrid Pan & Tilt Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support fire detection & alarm
> Max 90°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8421A-T Thermal Network Hybrid Pan & Tilt Camera
TPC-PT8421A-T
Thermal Network Hybrid Pan & Tilt Camera
> 400 × 300 uncooled VOx thermal sensor technology
> Athermalized lens (thermal), focus-free
> 1/2.8” 2 megapixel progressive scan CMOS
> Support temperature measurement
> Support detection and alarm of fire
> Max 140°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8421C Thermal Network Hybrid PTZ Camera
TPC-PT8421C
Thermal Network Hybrid PTZ Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized lens(thermal), focus-free
> 2 Megapixel progressive scan CMOS
> Powerful optical zoom lens(thermal&visible)
> Support fire detection & alarm
> Max 30°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/1 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8620B Thermal Network Hybrid PTZ
TPC-PT8620B
Thermal Network Hybrid PTZ
Recommended Replacement:
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful optical zoom lens(Thermal&Visible)
> Support fire detection & alarm
> Max 12°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8441D-BM-DC48-S23(Only For Project)) DAHUA TPC-PT8441D-BM-DC48-S23(OnlyForProject)) Thermal Network Multi-spectral Pan & Tilt Camera
TPC-PT8441D-BM-DC48-S23
(Only For Project))
Thermal Network Multi-spectral Pan & Tilt Camera
> Vanadium oxide uncooled focal plane detector.
> 1/1.8”4 Megapixel progressive scan CMOS.
> Visible lens offers 56× optical zoom.
> Offers various AI functions such as heat detection, smoke detection, tripwire, intrusion, boat detection, human/vehicle classification.
> Optical Image Stabilization.
> Optical defog.
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern.
> 7/2 alarm in/out.
> Micro SD memory, IP66.
> Laser illumination distance ≥ 800 m/500 m (optional).
DAHUA TPC-PT8620A-TB Thermal Network Hybrid Pan & Tilt Camera
TPC-PT8620A-TB
Thermal Network Hybrid Pan & Tilt Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support temperature measurement
> Support fire detection & alarm
> Max 160°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP67
DAHUA TPC-PT8621A Thermal Network Hybrid Pan & Tilt Camera
TPC-PT8621A
Thermal Network Hybrid Pan & Tilt Camera
> 640 × 512 VOx uncooled thermal sensor technology
> Athermalized lens(thermal), focus-free
> 1/2.8” 2 megapixel progressive scan CMOS
> Support detection and alarm of fire
> Max 140°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8620M-B Thermal Network Mobile Hybrid Pan & Tilt Camera
TPC-PT8620M-B
Thermal Network Mobile Hybrid Pan & Tilt Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support fire detection & alarm
> Max 90°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8620M-TB Thermal Network Mobile Hybrid Pan & Tilt Camera
TPC-PT8620M-TB
Thermal Network Mobile Hybrid Pan & Tilt Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support temperature measurement
> Support fire detection & alarm
> Max 90°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8621A-T Thermal Network Hybrid Pan & Tilt Camera
TPC-PT8621A-T
Thermal Network Hybrid Pan & Tilt Camera
> 640 × 512 uncooled VOx thermal sensor technology
> Athermalized lens (thermal), focus-free
> 1/2.8” 2 megapixel progressive scan CMOS
> Support temperature measurement
> Support detection and alarm of fire
> Max 140°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-PT8621C(Only for project) DAHUA TPC-PT8621C(Onlyforproject) Thermal Network Hybrid PTZ Camera
TPC-PT8621C
(Only for project)
Thermal Network Hybrid PTZ Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized lens(thermal), focus-free
> 2 Megapixel progressive scan CMOS
> Powerful optical zoom lens(thermal&visible)
> Support fire detection & alarm
> Max 30°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 2/1 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-SD2221-T Thermal Network Hybrid Speed Dome
TPC-SD2221-T
Thermal Network Hybrid Speed Dome
> 256×192 VOx uncooled thermal sensor technology
> Athermalized lens (thermal camera), focus-free
> 1080P Full-HD image display
> Support ROI, motion detection, color palettes
> Support temperature measurement
> Support smoking detection
> Smart alarm linkage with white light & loudspeaker
> Built-in 2/1 alarm in/out
> Micro SD memory
> Support Fire detection & alarm
DAHUA TPC-PT8641D Thermal Network Multi-spectral Pan & Tilt Camera
TPC-PT8641D
Thermal Network Multi-spectral Pan & Tilt Camera
> 1/1.8”4 Megapixel progressive scan CMOS.
> Visible lens offers 56× optical zoom.
> Offers various AI functions such as heat detection, smoke detection, tripwire, intrusion, boat detection, human/vehicle classification.
> Optical Image Stabilization.
> Optical defog.
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern.
> 7/2 alarm in/out.
> Micro SD memory, IP66.
> Laser illumination distance ≥ 800 m (optional).
DAHUA TPC-SD2221 Thermal Network Value Hybrid Speed Dome Camera
TPC-SD2221
Thermal Network Value Hybrid Speed Dome Camera
> 256×192 VOx uncooled thermal sensor technology
> 1/2.8” 2Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Smart alarm linkage with white light & loudspeaker
> Support Fire detection & alarm
> Up to 300 presets, 5 auto scan, 8 tour, 5 patern
> Built-in 2/1 alarm in/out
> Micro SD memory, IP66, PoE
DAHUA TPC-SD2241 Thermal Network Hybrid Speed Dome Camera
TPC-SD2241
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: heat detection, tripwire, intrusion, human/vehicle classification, smoking detection, and call detection.
> Built-in white light and audio alarm.
> Pan: 0° to 360°, tilt: –15° to +90°.
> Dual image fusion (visible and thermal images).
> Wide input voltage 12 VDC ± 20%, and PoE.
> IP66 rated.
DAHUA TPC-SD2241-T Thermal Network Hybrid Speed Dome Camera
TPC-SD2241-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Offers various AI functions such as intrusion, target filtering, heat detection, smoking detection, and calling detection.
> Temperature measurement range of –20 °C to +550 °C (-4 °F to +1022 °F).
> Built-in white light and speaker that produce light and sound alarms to deter intruders.
> IBuilt-in IR LED, and the max. illumination distance is 35 m.
> Wide monitoring range: Pan: 0° to 360° endless tilt: –15° to +90°.
> Dual image fusion (visible and thermal images).
> 12 VDC ± 20%/PoE+ power supply.
> IP66 rated.
DAHUA TPC-SD5441 Thermal Hybrid Speed Dome Camera
TPC-SD5441
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Visible lens offers 45× optical zoom.
> AI functions: boat detection, heat detection, tripwire, intrusion, and human/vehicle classification.
> Maximum IR illumination distance is 100 m.
> Dual image fusion (visible and thermal images).
> Pan: 0° to 360°, tilt: –10° to +90°.
> Wide input voltage 36 VDC ± 50%, and Hi-PoE.
> IP66 rated.
DAHUA TPC-SD5641 Thermal Hybrid Speed Dome Camera
TPC-SD5641
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Visible lens offers 45× optical zoom.
> AI functions: boat detection, heat detection, tripwire, intrusion, and human/vehicle classification.
> Maximum IR illumination distance is 100 m.
> Dual image fusion (visible and thermal images).
> Pan: 0° to 360°, tilt: –10° to +90°.
> Wide input voltage 36 VDC ± 50%, and Hi-PoE.
> IP66 rated.
DAHUA TPC-SD5641-T Thermal Hybrid Speed Dome Camera
TPC-SD5641-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Visible lens offers 45× optical zoom.
> Offers various AI functions such as boat, smoke, and heat detection, tripwire, target filtering and intrusion detection.
> Built-in IR LED, and the IR illumination distance ≥100 m.
> Dual image fusion (visible and thermal images).
> 36 VDC ± 50%/Hi-PoE power supply.
> IP66 rated.
> Temperature measurement range of –20 °C to +550 °C.
DAHUA TPC-SD8421-T Thermal Network Hybrid Speed Dome
TPC-SD8421-T
> 400 × 300 uncooled VOx thermal sensor technology
> Athermalized lens (thermal), focus-free
> 1/2.8” 2 megapixel progressive scan CMOS
> Support detection and alarm of fire
> Max 140°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
> Support temperature measurement
DAHUA TPC-SD8420-TB Thermal Network Hybrid Speed Dome Camera
TPC-SD8420-TB
Thermal Network Hybrid Speed Dome Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support temperature measurement
> Support fire detection & alarm
> Max 240°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-SD8421(only for project) DAHUA TPC-SD8421(onlyforproject) Thermal Network Hybrid Speed Dome Camera
TPC-SD8421
(only for project)
Thermal Network Hybrid Speed Dome Camera
> 400×300 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/2.8” 2Megapixel progressive scan CMOS
> Powerful 45X optical zoom
> Support fire detection & alarm
> Max 240°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-SD8621-T Thermal Network Hybrid Speed Dome
TPC-SD8621-T
> 640 × 512 uncooled VOx thermal sensor technology
> Athermalized lens (thermal), focus-free
> 1/2.8” 2 megapixel progressive scan CMOS
> Support detection and alarm of fire
> Max 140°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
> Support temperature measurement
DAHUA TPC-SD8621 Thermal Network Hybrid Speed Dome Camera
TPC-SD8621
Thermal Network Hybrid Speed Dome Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/2.8” 2Megapixel progressive scan CMOS
> Powerful 45X optical zoom
> Support fire detection & alarm
> Max 240°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-SD8620-TB Thermal Network Hybrid Speed Dome Camera
TPC-SD8620-TB
Thermal Network Hybrid Speed Dome Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.9” 2Megapixel progressive scan Sony CMOS
> Powerful 30x optical zoom
> Support temperature measurement
> Support fire detection & alarm
> Max 240°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-SDT8621 Thermal Network Hybrid Speed Dome Camera
TPC-SDT8621
Thermal Network Hybrid Speed Dome Camera
> 640×512 VOx uncooled thermal sensor technology
> Athermalized Lens(thermal), Focus-free
> 1/1.8” 4Megapixel progressive scan CMOS
> Powerful 45X optical zoom
> Support fire detection & alarm
> Max 200°/s pan speed, 360° endless pan rotation
> Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
> 7/2 alarm in/out
> Micro SD memory, IP66
DAHUA TPC-AEBF5441-T Thermal Network Explosion-proof Hybrid Bullet Camera
TPC-AEBF5441-T
Thermal Network Explosion-proof Hybrid Bullet Camera
> Supports up to 18 color palettes.
> 4Megapixel progressive scan CMOS.
> High-precision non-contact temperature measurement.
> Explosion-proof certification: II 2G Ex db IIC T6 Gb/II 2D Ex tb IIIC T80 °C Db.
DAHUA TPC-AEBF5641-T Thermal Network Explosion-proof Hybrid Bullet Camera
TPC-AEBF5641-T
Thermal Network Explosion-proof Hybrid Bullet Camera
> Supports up to 18 color palettes.
> 4Megapixel progressive scan CMOS.
> High-precision non-contact temperature measurement.
> Explosion-proof certification: II 2G Ex db IIC T6 Gb/II 2D Ex tb IIIC T80 °C Db.
DAHUA TPC-AEBF5201-T Thermal Network Explosion-proof Bullet Camera
TPC-AEBF5201-T
Thermal Network Explosion-proof Bullet Camera
> Supports up to 18 color palettes.
> High-precision non-contact temperature measurement.
> Explosion-proof certification: II 2G Ex db IIC T6 Gb/II 2D Ex tb IIIC T80 °C Db.
DAHUA TPC-PT8441MA-T Thermal Network Mini Hybrid Pan & Tilt Camera
TPC-PT8441MA-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: face priority, heat detection, tripwire, intrusion, and human/vehicle classification.
> Temperature measurement range of –20 °C to +550 °C.
> PTZ with encoder.
> Pan: 0° to 360°, tilt: –90° to 90°.
> Wide input voltage of 10–36 VDC.
> Auto rain-sensing wiper.
> Maximum IR illumination distance is 100 m.
> IP66 rated.
DAHUA TPC-BF5641-AC Thermal Network Anti-corrosion Hybrid Bullet Camera
TPC-BF5641-AC
> Vanadium oxide uncooled focal plane detector.
> 1/1.8″ 4Megapixel progressive scan CMOS.
> Heat detection and alarm, tripwire, intrusion, and target filtering.
> Illumination distance is up to 80 m.
> IP67 rated.
> Wide input voltage 12 VDC ± 20%, and PoE power supply.
> Smart linkage of white light and audio.
> Anti-corrosion
DAHUA TPC-BF5441-AC Thermal Network Anti-corrosion Hybrid Bullet Camera
TPC-BF5441-AC
> Vanadium oxide uncooled focal plane detector.
> 1/1.8″ 4Megapixel progressive scan CMOS.
> Heat detection and alarm, tripwire, intrusion, and target filtering.
> Illumination distance is up to 80 m.
> IP67 rated.
> Wide input voltage 12 VDC ± 20%, and PoE power supply.
> Smart linkage of white light and audio.
> Anti-corrosion
DAHUA TPC-SD5641-AC Thermal Network Anti-corrosion Hybrid Speed Dome Camera
TPC-SD5641-AC
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: boat detection, heat detection, tripwire, intrusion, and human/vehicle classification.
> Maximum IR illumination distance is 100 m.
> Pan: 0° to 360°, tilt: –10° to +90°.
> 36 VDC ± 50%/Hi-PoE+ power supply.
> IP66 rated.
> Anti-corrosion
DAHUA TPC-SD5441-AC Thermal Network Anti-corrosion Hybrid Speed Dome Camera
TPC-SD5441-AC
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: boat detection, heat detection, tripwire, intrusion, and human/vehicle classification.
> Maximum IR illumination distance is 100 m.
> Pan: 0° to 360°, tilt: –10° to +90°.
> 36 VDC ± 50%/Hi-PoE+ power supply.
> IP66 rated.
> Anti-corrosion
DAHUA TPC-PT8641D-AC Thermal Network Anti-corrosion Multi-spectral Pan & Tilt Camera
TPC-PT8641D-AC
> Vanadium oxide uncooled focal plane detector.
> 4 Megapixel progressive scan CMOS.
> AI functions such as heat detection, smoke detection, tripwire, intrusion, boat detection, human/vehicle classification.
> Pan: 0° to 360° endless, tilt: –45° to +90°.
> Optical defog and Optical Image Stabilization (OIS).
> Auto rain-sensing wiper.
> Wide input voltage 24–57 VDC.
> IP66 rated.
> Anti-corrosion
DAHUA TPC-PT8641C-AC Thermal Network Anti-corrosion Hybrid PTZ Camera
TPC-PT8641C-AC
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Vari-focus thermal lens.
> Pan: 0° to 360°, tilt: –45° to +60°.
> AI functions: heat detection, tripwire, intrusion, and human/vehicle classification.
> Auto rain-sensing wiper.
> Optical defog and Optical Image Stabilization (OIS).
> Wide input voltage 100–300 VAC.
> Anti-corrosion.
DAHUA TPC-PT8441D-AC Thermal Network Anti-corrosion Multi-spectral Pan & Tilt Camera
TPC-PT8441D-AC
> Vanadium oxide uncooled focal plane detector.
> 4 Megapixel progressive scan CMOS.
> AI functions such as heat detection, smoke detection, tripwire, intrusion, boat detection, human/vehicle classification.
> Pan: 0° to 360° endless, tilt: –45° to +90°.
> Optical defog and Optical Image Stabilization (OIS).
> Auto rain-sensing wiper.
> Wide input voltage 24–57 VDC.
> IP66 rated.
> Anti-corrosion
DAHUA TPC-PT8641MA-T Thermal Network Mini Hybrid Pan & Tilt Camera
TPC-PT8641MA-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: face priority, heat detection, tripwire, intrusion, and human/vehicle classification.
> Temperature measurement range of –20 °C to +550 °C.
> PTZ with encoder.
> Pan: 0° to 360°, tilt: –90° to 90°.
> Wide input voltage of 10–36 VDC.
> Auto rain-sensing wiper.
> Maximum IR illumination distance is 100 m.
> IP66 rated.
DAHUA TPC-PT8641MA-T Thermal Network Mini Hybrid Pan & Tilt Camera
TPC-PT8641MA-T
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> Powerful 45x optical zoom Support tripwire, intrusion, and human/ vehicle classification.
> Temperature measurement range of ¨C20 ¡ãC to +550 ¡ãC.
> Pan: 0¡ã to 360¡ã, tilt: ¨C90¡ã to 90¡ã.
> Wide input voltage of 10¨C36 VDC.
> Maximum IR illumination distance is 100 m.
> IP66 rated.
DAHUA TPC-BF5601-S2_V2 Thermal Network Bullet Camera
TPC-BF5601-S2_V2
Thermal Network Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> AI functions: heat detection, tripwire, intrusion, and human/vehicle classification.
> Wide input voltage 12 VDC ¡À 20%, and PoE.
> IP67 rated.
DAHUA TPC-PT8641MA Thermal Network Mini Hybrid Pan & Tilt Camera
TPC-PT8641MA
> Vanadium oxide uncooled focal plane detector.
> 4Megapixel progressive scan CMOS.
> AI functions: face priority, heat detection, tripwire, intrusion, and human/vehicle classification.
> PTZ with encoder.
> Pan: 0¡ã to 360¡ã, tilt: ¨C90¡ã to 90¡ã.
> Wide input voltage of 10¨C36 VDC.
> Auto rain-sensing wiper.
> Maximum IR illumination distance is 100 m.
> IP66 rated.
DAHUA TPC-SDA8441 Thermal Network Smart Linkage Camera
TPC-SDA8441
> Vanadium oxide uncooled focal plane detector.
> Starlight 1/1.8″ 4Megapixel progressive scan CMOS.
> Thermal PTZ: Pan: 0¡ã to 190¡ã, tilt: ¨C5¡ã to 180¡ã.
> Visible PTZ: Pan: 0¡ã to 360¡ã, tilt: ¨C30¡ã to 90¡ã.
> Visible lens offers 45¡Á optical zoom.
> Thermal and visible channel linkage tracking.
> Offers various AI functions such as tripwire, target filtering and intrusion detection.
> Two-way audio, sound and light alarm.
> IR illumination distance ¡Ý250 m.
> Wide input voltage of 36 VDC ¡À 25%.
> IP66 rated.
DAHUA TPC-BF5601-T-S2_V2 Thermal Network Bullet Camera
TPC-BF5601-T-S2_V2
Thermal Network Bullet Camera
> Vanadium oxide uncooled focal plane detector.
> AI functions: heat detection, tripwire, intrusion, and human/vehicle classification.
> Wide input voltage 12 VDC ¡À 20%, and PoE.
> IP67 rated.
DAHUA TPC-M40 Thermal Monocular Camera
TPC-M40
> Vanadium oxide uncooled focal plane detector.
> Ultra-low power consumption.
> Fire detection and alarm.
> Connects to the mobile app through Wi-Fi.
> Connects to the external display through the CVBS port.
> Provides a laser for aiming.
> Calculates distance using video analysis.
> Lightweight and portable.
> IP67 rated.
DAHUA TPC-M20 Thermal Monocular Camera
TPC-M20
> Vanadium oxide uncooled focal plane detector.
> Ultra-low power consumption.
> Fire detection and alarm.
> Connects to the mobile app through Wi-Fi.
> Connects to the external display through the CVBS port.
> Provides a laser for aiming.
> Calculates distance using video analysis.
> Lightweight and portable.
> IP67 rated.
DAHUA TPC-M60 Thermal Monocular Camera
TPC-M60
> Vanadium oxide uncooled focal plane detector.
> Ultra-low power consumption.
> Fire detection and alarm.
> Connects to the mobile app through Wi-Fi.
> Connects to the external display through the CVBS port.
> Provides a laser for aiming.
> Calculates distance using video analysis.
> Lightweight and portable.
> IP67 rated.
DAHUA IPC-HDEW8841R-Z 4MP Explosion Proof IR Dome WizMind Network Camera
IPC-HDEW8841R-Z
8MP Explosion Proof IR Dome WizMind Network Camera
* The parameters and datasheets below can only be applied to 8841-S2 series.
> 8-MP 1/2.8″ CMOS image sensor, low illuminance, high image definition.
> Outputs max. 8 MP (3840 × 2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Supports the AFSA(Anti-flicker Self-adaption) function, which automatically eliminates flicker.
> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, face exposure, and face attributes.
> People counting: People counting in area, queue management, and entered/exited people counting; generating and exporting report (day/ month/year).
> Intelligent monitoring: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human), abandoned object, missing object, loitering detection, people gathering, parking detection, heat map, and face detection.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; supports max. 256 G Micro SD card.
> 12 VDC/PoE power supply, easy for installation.
> IP68 and IK10 protection.
> Explosion-proof mark II 2 G Ex db IIC T6/T5 Gb; II 2 D Ex tb IIIC T80°C/ T100°C Db.
> 316 stainless steel casing, 2 m cable.
> ATEX and IECEx Certifacation.
> SMD 3.0.
DAHUA SDZW2000T-SL 2MP Anti-corrosion IR Network Camera
SDZW2000T-SL
2MP Anti-corrosion IR Network Camera
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> IVS
> IP68, IK10, NEMA 4X
> Material: 316L Stainless Steel
DAHUA SD8A840PA-HNF-SL 8MP 40?? Anti-corrosion WizMind PTZ Camera
SD8A840PA-HNF-SL
> 40x optical zoom.
> Starlight technology.
> IR distance up to 500 m.
> Auto-tracking.
> Perimeter protection.
> Face detection.
> Face recognition.
> Metadata.
> IP67.
> Anti-corrosion coating.
DAHUA SD60230U-HNI-SL 2MP 30x Anti-corrosion PTZ Network Camera
SD60230U-HNI-SL
2MP 30x Anti-corrosion PTZ Network Camera
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IP68, IK10, NEMA 4X
> Material: 316L Stainless steel
DAHUA EPC230U 2MP 30x Explosion-proof IR Network Camera
EPC230U
2MP 30x Explosion-proof IR Network Camera
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> 304 stainless steel housing
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> Support IVS
> IR distance up to 100m
> ATEX and IECEx Certifacation
> IP68
DAHUA EPC230U-PTZ-IR DAHUA EPC230U-PTZ 2MP 30x Explosion-proof Network Positioning System
EPC230U-PTZ-IR
2MP 30x Explosion-proof IR Network Positioning System
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> 316L stainless steel housing
> Starlight technology
> H.265/H.264 Triple-stream Encoding
> Max. 50/60fps@1080P
> IR distance up to 100m
> IP68
DAHUA EPC245U-PTZ 2MP 45x Explosion-proof Network Positioning System
EPC245U-PTZ
2MP 45x Explosion-proof Network Positioning System
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 45x optical zoom
> 316L stainless steel housing
> Starlight technology
> H.265/H.264 Triple-stream Encoding
> Max. 50/60fps@1080P
> IP68
DAHUA EPC230U-PTZ-IR 2MP 30x Explosion-proof IR Network Positioning System
EPC230U-PTZ-IR
2MP 30x Explosion-proof IR Network Positioning System
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> 316L stainless steel housing
> Starlight technology
> H.265/H.264 Triple-stream Encoding
> Max. 50/60fps@1080P
> IR distance up to 100m
> IP68
DAHUA EPC245U-PTZ-IR 2MP 45x Explosion-proof IR Network Positioning System
EPC245U-PTZ-IR
2MP 45x Explosion-proof IR Network Positioning System
> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 45x optical zoom
> 316L stainless steel housing
> Starlight technology
> H.265/H.264 Triple-stream Encoding
> Max. 50/60fps@1080P
> IR distance up to 200m
> IP68
DAHUA ECA3A1404-HNR-XB-F 4MP 4x Explosion-proof IR WizMind Network Camera
ECA3A1404-HNR-XB-F
> 4x optical zoom and 16x digital zoom
> Adopts anti-corrosion stainless steel 304, and 316L is customizable
> Starlight technology
> Max. 25/30 fps@4M
> IR distance up to 40 m
> SMD Plus
> Supports perimeter protection, smart capture, and face detection
> Optical Fiber
DAHUA ECA3A1404-HNR-XB 4MP 4x Explosion-proof IR WizMind Network Camera
ECA3A1404-HNR-XB
> 4x optical zoom and 16x digital zoom
> Adopts anti-corrosion stainless steel 304, and 316L is customizable
> Starlight technology
> Max. 25/30 fps@4M
> IR distance up to 40 m
> SMD Plus
> Supports perimeter protection, smart capture, and face detection
DAHUA ECA7A1425-HNR-XA-F 4MP 25x Starlight IR WizMind Explosion-proof Network Camera
ECA7A1425-HNR-XA-F
4MP 25x Starlight IR WizMind Explosion-proof Network Camera
> 1/1.8″ 4Megapixel CMOS
> 25x optical zoom (5.4 mm–135 mm)
> Starlight technology
> Max. 25/30fps@4MP
> IR distance up to 100 m
> Perimeter protection
> Face detection
> Smart Capture
> SMD PLUS
> Fiber port
DAHUA ECA7B1231-HNP-XA-F 2MP 31??Starlight IR EXPLOSION-PROOF CAMERA
ECA7B1231-HNP-XA-F
> 31× optical zoom.
> Starlight technology.
> Max. 25/30 fps@1080p
> IR distance up to 100 m.
> H.265 encoding.
> Perimeter protection.
> Face detection.
> Wiper.
> Optical Fiber.
> Support helmet detection and helmet color recognition.
DAHUA ECA2A1400-HN 4MP Starlight IR Explosion-proof Camera
ECA2A1400-HN
4MP Starlight IR Explosion-proof Camera
> 4-MP 1/2.8″ CMOS.
> Starlight technology.
> Max.25/30 fps@1080p.
> IR distance up to 30 m.
> H.265 encoding.
> 304 stainless steel housing.
> IP68. ATEX and IECEx certification.
DAHUA IPC-HDEW8441R-Z 4MP Explosion Proof IR Dome WizMind Network Camera
IPC-HDEW8441R-Z
* The parameters and datasheets below can only be applied to 8441-S2 series.
> 4-MP 1/3.0″ CMOS image sensor, low illuminance, high image definition.
> Outputs max. 4 MP (2688 × 1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Supports the AFSA(Anti-flicker Self-adaption) function, which automatically eliminates flicker.
> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, face exposure, and face attributes.
> People counting: People counting in area, queue management, and entered/exited people counting; generating and exporting report (day/ month/year).
> Intelligent monitoring: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human). abandoned object, missing object, loitering detection, people gathering, parking detection, heat map, and face detection.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; supports max. 256 G Micro SD card.
> 12 VDC/PoE power supply, easy for installation.
> IP68 and IK10 protection.
> Explosion-proof mark II 2 G Ex db IIC T6/T5 Gb; II 2 D Ex tb IIIC T80°C/ T100°C Db.
> 316 stainless steel casing, 2 m cable.
> ATEX and IECEx Certifacation.
> SMD 3.0.
DAHUA VTM117 +Surface Mounted Box
VTM117
VTM117+Surface Mounted Box
> Material: ADC12
> Dimensions: 97.0mm×199.0mm×29.0mm (3.82″×7.83″×1.14″)
DAHUA VTM123 Desktop Mounted Bracket
VTM123
Desktop Mounted Bracket
> Size: 190mm*100mm*54mm
> Dip angle: 45°
> Desktop mounted bracket for indoor monitor
DAHUA VTM115 +Surface mounted Box
VTM115
VTM115+Surface mounted Box
> Dimensions: 129.0mm×95.0mm×28.5mm (5.08″×3.74″×1.12″)
DAHUA VTNC1003C 2-wire Controller
VTNC1003C
2-wire Controller
DAHUA VTM59D Desktop Support
VTM59D
Desktop Support
> Made from aluminium alloy and features paint coating on the surface.
> Matches 7″ indoor monitor.
> Supports indoor monitors of multiple models, including model D, E, F, G, H, and K
DAHUA VTM57 Accessories of Villa Door Station
DAHUA VTM58 Accessories of Villa Door Station
DAHUA VTM60D Desktop Support
VTM60D
> Made from aluminium alloy and features paint coating on the surface.
> Matches 10″ indoor monitor.
> Supports indoor monitors of multiple models, including model D, E, F, G, H, and K.
DAHUA PFA156 Pole Mount Bracket
PFA156
Pole Mount Bracket
> Built of aluminum alloy and is cost-effective.
> Suitable for a variety of cameras and is elegant.
DAHUA PFA157 Pole Mount Bracket
PFA157
Pole Mount Bracket
> Built of aluminum alloy and is cost-effective.
> Suitable for a variety of cameras and is elegant.
DAHUA VTM114 +Flush Mounted Box
VTM114
VTM114+Flush Mounted Box
> Material: ADC12
> Dimensions(Front) : 128.9mm×162.9mm×34.5mm (5.08″×6.42″×1.36″)
> Dimensions(rear) : 123.0mm×157.0mm×35.0mm (4.84″×6.18″×1.38″)
> Wall Opening Dimensions: ＞113.0mm×149.0mm×35.0mm (4.45″×5.87″×1.38″) ，＜123.0mm×157.0mm×35.0mm (4.84″×6.18″×1.38″)
DAHUA VTOB103 Flush Mounted Box for VTO1210C-X
VTOB103
Flush Mounted Box for VTO1210C-X
> Size: 126mm*389mm*71mm
> Weight: 0.5 Kg
> Flush mounted box
DAHUA PFA10C Mount Adapter
DAHUA VTM116-01 +Flush mounted box
VTM116-01
> Material: ADC12
> Dimensions(Front) : 138.0mm×240.0mm×35.0mm(5.43″×9.45″×1.38″)
> Dimensions(rear) : 120.8mm×222.7mm×33.0mm (4.76″×8.77″×1.30″)
> Wall Opening Dimensions: 120.8mm×222.7mm×33.0mm(4.76″×8.77″×1.30″)
DAHUA VTOB119 Flush Mounted Box for VTO9231D
VTOB119
Flush Mounted Box for VTO9231D
> Size: 144mm*452mm*69mm
> Weight: 1.2 Kg
> Flush mounted box
DAHUA DEE1010B-S2 Access Control Extension Module
DEE1010B-S2
Access Control Extension Module
> Supports RS-485 communication.
> Connects to electronic or magnetic locks to bolster security.
> Offers 3 indicators to indicate when the device is on or off, functioning, and the status of the door.
DAHUA PFA130-E Water-proof Junction Box
PFA130-E
Water-proof Junction Box
>Neat & Integrated design
>Material: Aluminum
>IP66 junction box
DAHUA VTNS1060A Network power supply for IP System
VTNS1060A
Network power supply for IP System
> Protocol network power supply switch
> Connect max 6 indoor monitors with the Cat 5e cable, transfer the signal and power together
DAHUA VTM121 Flush Mount Plate of 8 Inch Face Recognition Outdoor Station
VTM121
Flush Mount Plate of 8 Inch Face Recognition Outdoor Station
> Flush Mount
DAHUA PFB206W Wall Mount Bracket
PFB206W
Wall Mount Bracket
> Built of aluminum alloy and is cost-effective.
> Suitable for a variety of cameras and is elegant.
DAHUA VTM125/VTM126 Panel
VTM125/VTM126
Panel
DAHUA VTM130 Surface Mounting Plate for VTO65/75 Series Door Station
DAHUA VTM25P2 Panel
DAHUA VTM127/VTM128 Mount box
VTM127/VTM128
Mount box
Model :VTM127
Color :Silver
Dimensions :133mm×233.20mm×68.0mm(5.24”×9.18”×2.68”)
Installation mode :Supports surface mounting and flush mounting Panel
Material :Aluminum
Model :VTM128
Appearance color :Silver
Dimensions 133mm×333.40mm×68.0mm(5.24”×13.13”×2.68”)
Installation mode ：Supports surface mounting and flush mounting Panel
Material :Aluminum
DAHUA PFM320-020US 12V DC 2A Power Adapter
PFM320-020US
12V DC 2A Power Adapter
> 100Vac¨C240 Vac wide input voltage range, meet the requirements in different parts for electric network fluctuation.
> Easy installation.
> V level of energy efficiency
> Over current, over voltage and other multiple protection
> Shell flame resistance V-0 level.
DAHUA PFM320-020EN 12V DC 2A Power Adapter
PFM320-020EN
12V DC 2A Power Adapter
> 100Vac¨C240 Vac wide input voltage range, meet the requirements in different parts for electric network fluctuation
> Easy installation
> VI level of energy efficiency
> Over current, over voltage and other multiple protection
> Shell flame resistance V-0 level
DAHUA PFM320-010US 12V DC 1A Power Adapter
PFM320-010US
12V DC 1A Power Adapter
> 100Vac¨C240 Vac wide input voltage range, meet the requirements in different parts for electric network fluctuation.
> Easy installation.
> V level of energy efficiency
> Over current, over voltage and other multiple protection
> Shell flame resistance V-0 level.
DAHUA PFM320-010EN 12V DC 1A Power Adapter
PFM320-010EN
12V DC 1A Power Adapter
> 100Vac¨C240 Vac wide input voltage range, meet the requirements in different parts for electric network fluctuation.
> Easy installation.
> VI level of energy efficiency
> Over current, over voltage and other multiple protection
> Shell flame resistance V-0 level.
DAHUA KIT/DH-PFM378-B125-CB/DH-SD49425DB-HNY-GQ-LA Integrated Solar Monitoring System(Without Lithium Battery)
KIT/DH-PFM378-B125-CB/DH-SD49425DB-HNY-GQ-LA
> Angle flexible adjustment of solar panel and camera mount.
> 125 W Monocrystalline solar panel.
> Aluminum alloy frame.
> Built sturdy to resist storms with sustained winds up to 117 km/h. (Note: The following four functions are only supported when battery power is used.)
> Remote monitoring available through the mobile app.
> Maximum Power Point Tracking (MPPT) charging controller.
> RS-485 communication.
> Electric protection.
> 1/2.8″ 4Megapixel STARVIS? CMOS.
> 25x optical zoom.
> Starlight technology.
> Max. 25/30fps@4M.
> IR distance up to 100 m.
> Perimeter protection.
> Face detection.
> SMD 3.0.
> IP66 rated.
> 4G.
DAHUA KIT/DH-PFM378-B125-CB/DH-SD49425DB-HNY-GQ-EAU Integrated Solar Monitoring System(Without Lithium Battery)
KIT/DH-PFM378-B125-CB/DH-SD49425DB-HNY-GQ-EAU
> Angle flexible adjustment of solar panel and camera mount.
> 125 W Monocrystalline solar panel.
> Aluminum alloy frame.
> Built sturdy to resist storms with sustained winds up to 117 km/h. (Note: The following four functions are only supported when battery power is used.)
> Remote monitoring available through the mobile app.
> Maximum Power Point Tracking (MPPT) charging controller.
> RS-485 communication.
> Electric protection.
> 1/2.8″ 4Megapixel STARVIS CMOS.
> 25x optical zoom.
> Starlight technology.
> Max. 25/30fps@4M.
> IR distance up to 100 m.
> Perimeter protection.
> Face detection.
> SMD 3.0.
> IP66 rated.
> 4G.
DAHUA PFM3640LS-D1B100 Integrated Solar System
PFM3640LS-D1B100
> The bracket is made of integrated galvanized steel, which is easy to install.
> IP66 rated.
> Self-heats when the battery temperature is 0 ¡ãC and stops at 5¡ãC to ensure that it can work in low temperatures.
> Reads its battery power data.
> The indicator light shows the device status in real time.
DAHUA PFM3620LS-D1B60 Integrated Solar System
PFM3620LS-D1B60
> The bracket is made of integrated galvanized steel, which is easy to install.
> IP66 rated.
> Self-heats when the battery temperature is 0 ¡ãC and stops at 5¡ãC to ensure that it can work in low temperatures.
> Reads its battery power data.
> The indicator light shows the device status in real time.
DAHUA PFM922I-5EUN-C-100 100m UTP CAT5e Cable
PFM922I-5EUN-C-100
100m UTP CAT5e Cable
> 100m (328.08 ft)/carton UTP CAT5e, power over Ethernet, compatible with one cable
